گتے کے ڈبے بنانے کی مشین Boix PF-4/EC + AMP/R

Boix PF-4 box erecting machine
FP-4 EC


- Operation – Mechanical, pneumatic and electrical
- Glue system – HOT-MELT injection (NORDSON)
- Production – 4 speeds from 900 to 1.400 boxes/hour
- Total power under working conditions Machine, stacker and compressor: 11,5 kW
- Net weight 2.740 kg
- Dimensions – L5.100 × W1.450 × H2.960 Size change
- Manual, by threaded rods with counters
- Size change time 15–45 min. approx. Introduction system
- By vacuum Traction motor reducer
- 1,5 kW (IEC 34-IP55) Vacuum pump
- 0,75 kW (VDE 530/91-IP54), capacity 25–30 m³/h, 150 mbar (abs.)
- Compressor (optional) – 4 kW, 7 bar, 10,4 L/s
- Working air pressure – 6 kg/cm²
- Air consumption – 420 l/min
- Sonority (1 m distance / 1,6 m height) 78 dB(A)
- Min. formed box size – 300 × 200 × 90 mm
- Max. formed box size – 600 × 400 × 250 mm
- Max. blank size – 1.100 × 820 mm
- NORDSON – 3706


AMP/R stacker with the boxes


- Makes 400 x 300 mm boxes in various heights (all other possible sizes require optional Boix tooling.)
- Number of boxes produced: 51,800,000
- The machine has been serviced annually



More information or a quote? Do this quick and easily via the Duijndam Machines website! You can also give us a call.

See all the available machines at our website.


- Since 1977 supplier of reliable used agricultural and horticultural equipment
- Machines are checked for delivery
- Experienced team
- We can help you with getting the machine to your company


Duijndam Machines
The specialist in used agriculture and horticulture machinery

= More information =

General condition: good
Price: On request
